The Philips Dynalite DDBC516FR is a five channel device for controlling DALI drivers. Each control output is selectable to DALI broadcast, DALI addressed, 1-10V or DSI.
Multiple protocols supported – Each of the five control outputs supports DALI broadcast (maximum ten DALI loads/channel), DALI addressed (maximum ten DALI loads/channel), 1-10V (maximum 10 mA sink or source/channel) or DSI (maximum five DSI loads/channel).
Built-in energy savings - Control signals can be programmed to operate in tandem with five internal switched outputs, which will automatically isolate the power circuit when all associated channels are at 0%. This is a useful feature as DALI drivers still draw significant power when lamps are turned off via a DALI command.
Integral DALI bus power supply - Removes the need for an additional external device.
Flexible mounting solution - A DIN-rail mountable device, designed to be installed into the distribution board supplying power to the controlled circuit.
Inbuilt diagnostic functionality - Features lamp and driver failure reporting, driver run time tracking for each driver and the switched output, as well as Device Online/Offline status indication.
